Exterior luminaire Flag
Rectangular luminaire.
Body Color:
Request Price
Description Flag
Wall-mounted rectangular luminaire with clean lines — all fixing elements are concealed inside the housing, eliminating external brackets or cables on the facade. Available with one or two light lines; in the dual-line version the lines are on opposite sides of the housing. The housing is made of aluminum profile. Integrated light lines use a diffuse or clear diffuser element without secondary optics. The power supply is installed inside. Can be manufactured to any required project length without additional changes. Standard lengths per the table; custom lengths from 300 to 3000 mm in 50 mm increments.
Specifications
Parameters
Dimensions, mm
120×50×2000
Power, W
2×20 W
Optics
Diffuse
Color Temperature
3000K, 4000K, RGBW
IP Rating
66
Power Supply
Built-in
Supply Voltage
230 V 50-60 Hz
Mounting Method
Surface-mounted
Accessories
Cable connectors, junction boxes
Control
DALI, 1-10V, DMX512, DMX-RDM (details available from manufacturer)
Flag luminaire
in completed projects
in completed projects
The Flag lighting system is designed to provide uniform and comfortable illumination.
Projects with Flag
